The Bell 412EP is the daily workhorse that reliably performs in some of the most extreme climates around the world every day. Its expansive cabin provides multi-mission flexibility while its wide opening 7.7 ft. doors easily accommodate forklift loadings into a spacious 220 ft.

  • 5,100

    lbs. Useful Load

  • 357

    nm Max Range

  • 14

    Passengers



Missions

When business requires you to travel in extreme conditions, look to the Bell 412EP to always get you there and back. The board of directors can be accommodated on the Bell 412EP with its spacious, configurable 220 ft3/6.2 m3 cabin. Also you can tote your guest's luggage easily with the Bell 412EP’s large 28 ft3/0.8 m3 baggage compartment.

The Bell 412EP is known as a true daily workhorse in the energy sector. The expansive cabin accommodates varying needs in a safe and reliable platform. Optional mission equipment for an energy configuration further enhances the Bell 412EP’s capability. Options include emergency floats with life rafts that mount to the skid gear in the event of a water landing, a Primus 700 radar that provides weather awareness and avoidance alerts, wire strike and a belly-mounted high intensity search light that provides night visibility.

When disaster strikes, you need extraordinary resources to respond. You need the Bell 412EP. The cabin features space to carry four medical attendants and up to six patients or two critical patients. The 7.7 ft/2.3 m. sliding doors on both sides of the Bell 412EP allow for fast and easy patient loading and unloading.

The Bell 412EP is as versatile as your daily requirements. As one of the roomiest, most flexible and cost-effective aircraft on the market, the Bell 412EP can be configured to an airborne command center, an air ambulance platform, special operations or a homeland security base. It can be equipped with an optional hoist and cargo hook for increased multi-mission capability, including search and rescue, firefighting, HEMS and mass evacuations.



Proven Power

Pratt & Whitney PT6T-3D Twin Pac®, with 4,000 hour TBOs, has a take-off rating of 1,800 shp/1,342 kW. An optional kit provides the use of an additional 96 shaft horsepower in OEI condition for 30 minutes. This reliable engine averages 166,700-hours mean time between in-flight engine shutdowns. This aircraft is ready with power when you need it.

BLR Strake and FastFin®

Bell Helicopter has partnered with BLR Aerospace to provide its performance, safety and efficiency enhancing Strake and FastFin® as a standard feature on new Bell 412EP aircraft orders. The system incorporates two parallel stall strips along the tail boom and a reshaped vertical fin. These modifications combine to optimize airflow around the tail boom, improving the handling, stability and lifting capacity of the Bell 412EP in all environments, especially high and hot conditions.

IFR

? Dual Pilot IFR with 3-Axis Dual Digital Automatic Flight Control System, Standard Equipment ? Certified for Single Pilot or Dual Pilot IFR

Safety in Mind

The Bell 412EP is equipped with a variety of safety features including: proven reliable engines, transmission with chip detection and debris collection, superb autorotation, rollover bulkheads and rupture resistant fuel cells. Optional additions that further enhance the Bell 412EP’s safety include, wire strike protection system, vibration monitor system, and self-sealing fuel cells.

Spacious Cabin

With useful load capability of 5,100 lbs/2,313 kg, seating for up to 14 passengers plus one pilot and cabin floor space of 52 ft²/5 m² the cabin of the Bell 412EP is highly configurable for any mission that calls for transporting crew and/or equipment.

Open Doors for Any Mission

Standard aft-sliding door and swing-out forward cabin door provide a 7.7 ft/2.3 m opening for quick and easy loading and unloading.



Specifications

SPEEDS AT MAX GROSS WEIGHT
    259 km/h
Max Cruise 122 kts 226 km/h
Range at VLRC* 357 nm 662 km
Max Endurance*   3.8 hrs
CAPACITIES
Standard Seating 1+14
Maximum Seating   1+14
Standard Fuel 331 US gal 1,251 litres
Aux Fuel 33 or 163 US gal 123 or 617 liters
Cabin Volume 220 ft³ 6.2 m³
Baggage Compartment Volume 28 ft³ 0.8 m³
WEIGHTS
Empty Weight (Base Aircraft) 6,800 lbs 3,084 kg
Useful Load (Internal, Base Aircraft) 5,100 lbs 2,313 kg
Max Gross Weight (Internal) 11,900 lbs 5,398 kg
Max Gross Weight (External) 11,900 lbs 5,398 kg
Cargo Hook Capacity 4,500 lbs 2,041 kg
*Max GW, ISA, Std fuel – no reserves at sea level
